Product Introduction
| The diameter of the fan blade | 550mm | |
Material | Guard Grill | steel, phosphated and coated in black plastic |
Wall ring | sheet steel, galvanized and coated in black plastic | |
blades | sheet steel | |
Rotor | encased in aluminium | |
Number of blades | 5 | |
Direction of rotation | Suction—direction of air flow "S" counter-clockwise, | |
Blowing—direction of air flow "B" clockwise seen on rotor | ||
Type of protection | IP54 or IP44 | |
Insulation class | Class B or Class F | |
Approvals | UL, CE, CCC , ROHS and so on | |
Mode of operation | Continuous operation(S1) | |
Bearings | Maintenance- free ball bearings | |
Ambient temperature | -30℃ to 60℃ | |
Motor protection | without TOP, TOP wired internally | |
Cable exit | lateral | |
Protection class | I | |
Advantage | YWF series axial fan with high static pressure and large air flow, have single phase, three phase, and different voltage levels, and 50HZ, 60HZ, according to the client’s different needs. | |
product Parameter (specification)
(1)For Air Compressor:
YWF550 usually use in air compressor of 22-30 KW
| Model | Voltage | Frequency | Current | Input Power | Speed | Max Air Flow | Capacitor | Noise |
YWF4D550 | 380 | 50 | 1.35 | 600 | 1300 | 9700 | / | 76 |
(2)For Refrigeration and others:
| Model | Voltage | Frequency | Current | Input Power | Speed | Max Air Flow | Capacitor | Noise dB(A) | Model |
YWF4E550 | 230 | 50/60 | 2.2/3.1 | 500/710 | 1320/1500 | 8250/8700 | 16 | 76/80 | ①② |
YWF4D550 | 400Y | 50/60 | 1.1/1.3 | 480/700 | 1320/1500 | 8250/8700 | / | 76/80 | |
YWF6E550 | 230 | 50/60 | 1.15/1.55 | 230/335 | 940/1100 | 5400/6400 | 10 | 66/71 | ③④ |
YWF6D550 | 400Y | 50/60 | 1.1/0.92 | 290/345 | 940/1100 | 5400/6400 | / | 66/71 |
Product feature and application
(1) Product feature:
●Compact structure
●Specialized design
●Refined process control
●Simple Installation
●High efficiency and low noise
●Long service life
Application
Ventilation | Buildings, parking lots and so on |
Refrigeration | Refrigerator, Air cooler, refrigerating machine and so on |
Heat dissipation | HAVC, Air compressor, Dehumidifier, Evaporator, Wall fan, Condenser, Dryer, AHU, Ice machine and so on |
Production details
The Research and Development Center
The Research and development center of Ningbo Lionball Ventilator Co., Ltd is a national R&D center. It is appraised as High-tech Enterprises and EngineeringTechnologyCenter and has obtained many important prizes in the provincial projects.
Research and development center currently has 25 staff members. We introduced Germanic technology and employed a well-paid fan expert as our technical adviser. What is more, we have cooperated with international renowned enterprise EMERSON for about 5 years and will hand in hand with Carrier China.
Research and development center are facilitated with modern equipment and advanced laboratories: Air flow laboratory and life testing laboratory. We provide each member with professional inspection equipment for better research environment.
Over the past two years, owing to continuous effort of R&D team, we have successively obtained 15 certificates of Utility Model patent and 2 certificates of Invention Patents.
(1)Our Certificates of Utility Model Patent
(2)Certificates of Invention Patent
